Case: Burger King Östersund

Lepido triples energy recovery in newly constructed restaurant

None of the previous attempts to cash in on the energy found in Scandinavian Burger King restaurants have been successful from an economic or technical perspective. Thanks to Lepido, recovered energy from Burger King Östersund is now redistributed to power ventilation and heating (tap water, floors and air) recovering a yearly total of 120 000 kWh.

Energy recovery in a specific Burger King restaurant with a Lepido unit installed. The orange curve shows the recovery from a similar restaurant using a different setup.
Energy recovery in a specific Burger King restaurant with a Lepido unit installed. The orange curve shows the recovery from a similar restaurant using a different setup.
Conditions
Restaurant: Burger King Östersund
Airflow: 1000 l/sec
Designable outdoor temperature: -20°C
Energy recovered: 120 000 kWh/year
Property owner: NP3 Fastigheter
Constructor: Fastec
Assembly: Teknisk klimatservice Norr AB
Operation: 16 hours
Exhaust temperature in air duct: 24°C
Desired inlet air temperature: 18°C
Starting operations in: June 2019

The recycled energy can be applied in many areas such as ventilation heating, pre-heating domestic water and radiator regulation.

Enjay_lepido_case_bk_house

In this project, the recycled energy is being used in:

1. Ventilation Heating
2. Pre Heating Domstic Water
3. Under Floor Heating

Average energy recovery per restaurant and year in kWh
