Case: Restaurant Färgstarkt

Energy recovery and cooling in a national monument protected building

There are limits to what you can do in a national monument protected building. This added a layer of complexity during the installation of an energy recovery system for restaurant Färgstarkt. Lepido was chosen thanks to its flexibility. The setup now recovers energy while delivering comfort ventilation.

A visual of the energy Lepido has recovered for Färgstarkt. Comfort cooling is not displayed in the graph.
A visual of the energy Lepido has recovered for Färgstarkt. Comfort cooling is not displayed in the graph.
Conditions
Restaurant: Färgstarkt, Lund
Airflow: 1200 l/sec
Designable outdoor temperature: -16°C
Energy recovered: 60 000 kWh/year
Property owner: Pär Lundberg Fastighets AB
Assembly: Assemblin Ventilation Malmö
Operation: 14 hours
Designable exhaust temperature in air duct: 24°C
Desired inlet air temperature: 20°C
Starting operations in: Aug 2019

The recycled energy can be applied in many areas such as ventilation heating, pre-heating domestic water and radiator regulation.

enjay_case_fargstarkt_house

In this project, the recycled energy is being used in:

1. Ventilation Heating

Average energy recovery per restaurant and year in kWh
